High Efficiency Automatic 380V/50HZ Tire Crusher Machine with 2200kg Weight and 22 Power for Waste Tire Recycling

Name: High Efficiency Automatic 380V50HZ Tire Crusher Machine with 2200kg Weight and 22 Power for Waste Tire Recycling
Brand: xrido
Price: 6 USD

Quality High Efficiency Automatic 380V/50HZ Tire Crusher Machine with 2200kg Weight and 22 Power for Waste Tire Recycling for sale

Place of Origin : Henan, China

Brand Name : xrido

Model Number : RDS-120

Certification : CE ISO

MOQ : 1 set

Price : $6,000-8,800 / set

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Motor

voltage : 380V/50HZ or customized

dimension(l*w*h) : 2800x1300x1850

warranty : 12 Months

key selling points : Automatic

weight (kg) : 2200

Power : 22

Application : Recycle Waste Tires

Raw material : Waste Tyre Tire Rubber

Key word : Waste Plastic Shredder

Color : Customers' Demand

Blade Material : 9CrSi/D2/SKD-11/ Customized

Waste tire recycling line : Tire Recycling Equipement Comeplete Line

Usage : Rubber Shredding Waste Plastic Shredding

Advantage : High Efficiency Low Energy Consumption

Shaft Design : Double

Contact Now

Products Description

The tire shredder is mainly used for pre shredding waste tires in the tire line. After passing through a sieve, appropriate sized tire fragments are screened and processed in the next step. Suitable for different types of waste tires, we can provide you with the best solution according to your different tires.

High Efficiency Automatic 380V/50HZ Tire Crusher Machine with 2200kg Weight and 22 Power for Waste Tire Recycling

Details Images

For different tire characteristics and productivity requirements,the line structure may include
1,Fully automatic wire drawing machine:remove tire steel wheel.

2,Conveyor equipment:conveyor belt,screw conveyor and air pressure transmission system.

3,Shredder:tear the tire into film (50mm-150mm).

4,Steel wire separator:separate the rubber and steel wire and
process it into rubber particles(10mm-20mm).

5,Magnetic separator:sorting steel wire from rubber wire mixture.

6,Crusher:Smash the
rubber particles to a smaller size(1mm-7mm).

7,Vibrating screen:sorting different sizes of rubber particles,and returning the
oversized particles to the crusher for secondary crushing.

8,Fiber separator:remove foreign matter and fiber.

9,Secondary Magnetic
Separator:Possible Small Wires to Go.

10,Mill:The particles are ground to a powder (30 mesh to 100 mesh).

11,Fully automatic bagging system:loading finished products into storage bags or bags.

Main Application

1. The whole tire is directly put in,no need to pre-break and pull the steel ring.

2, From the entire tire to 1-7mm granules, the
entire process of production packaging, no secondary handling intermediate links.

3, The maximum processing capacity is
5000kg/h,and only 7 people can complete the entire site operation.

4, According to the customer's output requirements
configuration equipment,200kg/h-5000kg/h,a wide range of options.

5,Fully-combined two-tier structure makes installation,
replacement, maintenance and maintenance more convenient and safer.

6,seamless connection, full dust, smoke monitoring
performance.

7, Adhere to the 80-100 hours feeding test before the single factory to ensure stable.

8.CE certification, uniform standards,focus on technology.

Product Paramenters

model	size(LxWxH)	blade diameter	blade quantity	weight
RDS-80	2800x1300x1850	275	72	3600
RDS-100	3000x1300x1850	275	96	4000
RDS-120	3300x1900x2200	315	120	6500
RDS-140	3600x2000x2200	315	144	7500
RDS-160	4180x2100x2400	350	180	9000
RDS-180	5400x2700x3500	500	240	20000

*This is the basic model of our shredder machine. Our factory manufactures customized machines according to the different requirements of different customers.

Feedback

It's our honor to be trusted by our customers. It's also the vision of our company. We are constantly pursuing the satisfaction and recognition from our customers. We are looking forward for every opportunity of cooperation. We also provide is installation direction and perfect after-sale service. We take every opinions of our customers priciously. That's the most important way to improve our service and customers' experience.

Company Profile

Our factory has a 16 years history of manufacturing customized machines for different clients with
different requirements. The price of machine and quality are guaranteed. We have been working in the field of environmental protection and recycling machinery for more than ten years. Countless customers have visited our factory and gained a deeper understanding of our machines. We welcome every customer who is willing to learn more about our factory to visit the factory. You can be accompanied by an engineer to explain technical parameters and personally test the operating status of the machine. We are committed to giving you the best service and experience.

FAQ

Q: Do you accept Custom-made?

A: Yes, we can custom the Tire Shredder machine according to clients requirements.
Q: How can i get a suitable Tire Shredder machine?
A: Tell us your requirements, such as raw material, out put size, capacity etc, our engineer can recommend the suitable
configuration and provide quotation for you.
Q: How long is your delivery time ?
A: 1 set for normal machine needs about 5 working days, if 1 or more containers, needs about 20 working days.
Q: How long is the warranty?
A: 1 year since the date of shipment, if parts failure or damage(because of the quality problem, except wearing parts), our
company will provide these parts for free.
Q:What is your payment term?
A: T/T 100% before shipment, L/C at sign, or Trade Assurance order recommended.
